BABY-LIN-3-Single

LIN bus simulator with USB interface

The Baby-LIN-3-Single is our most compact system for controlling LIN-BUS via USB. The PC can be used as LIN monitor, LIN master or LIN slave. The device also supports stand-alone use without a PC. Thus the test sequence can be defined as macro and the connection to the LIN bus is automatically activated. In addition, the isolated LIN interface is protected from ambient noise.

Deliverables

  • Baby-LIN-3-Single Equipment
  • USB-C 2.0 Cable, 1 Meter, Type A to Type C
  • 3-pole plug with screw connection (MC 1,5/ 3-ST-3,81)
  • License to download the LINWorks package (including LINWorks PC software, USB drivers, sample files and documentation)

Performance Overview

Applications

  • Expanded LIN interface for PC and Raspberry Pi
  • Supports a variety of bus simulations, which can be realized on the PC through LINWorks software or programmed applications.
  • PC-free, stand-alone mode operation (e.g. for durability testing)
  • Real-time reading and writing of frame data
  • Monitor a running LIN bus to view or record LIN frames
  • Data logging up to 100% bus workloads

Technical Features

  • Supports LIN bus versions 1.2, 1.3, 2.0, 2.1 and 2.2.
  • Electrical Isolation LIN Bus Interface
  • LIN master and LIN slave nodes can be simulated.
  • DTL (Diagnostic Transport Layer) Support Points
  • The LIN bus can be controlled from your own program via a DLL.
  • Operating voltage: 8-28V

Compatibility and system requirements

  • Windows 10/11 (32/64-bit)
  • DLL library interfaces: Windows (x86 and x64), PC-based Linux (x86 and x64), ARM-based Linux (x86 and x64)
  • Native programming in C/C++ is possible, as well as through the wrappers of .NET language, Python, VB6 and LabView.
