Pico Automotive Oscilloscope Complete Diagnostic Kit Series

The Hongke Pico Automotive Oscilloscope Diagnostic Kit includes a 2-channel/4-channel oscilloscope unit, smart PicoBNC+® probes, attenuator accessories, and dedicated PicoScope diagnostic software.With over 15 years of industry experience in automotive electronics and fault diagnosis, Hongke is committed to providing automotive repair shops, engineers, and educational institutions with precise and efficient oscilloscope testing solutions to help quickly troubleshoot complex circuit and bus faults.

List of Core Use Cases:

  • Engine and Ignition System Testing (Primary/Secondary Ignition)
  • CAN / CAN FD / LIN / FlexRay Bus Signal Analysis
  • Analysis of Fuel Injector and Sensor Waveforms
  • High-Voltage Safety and Electronic Control Testing for New Energy Vehicles
  • NVH: Vibration and Noise Diagnosis
Contact Us
Contact Us

Using PicoScope Automotive Manufacturer

Active Customers
0 K+
countries
0 +
Automobile Manufacturers
0 +
Years of experience
0

Pico Oscilloscope Kit

Enquiry on Quotation
Pico 4425A 汽車示波器診斷套裝外觀圖

Pico 4425A
Automotive Oscilloscope Kit

NVH 汽車示波器套裝外觀圖

NVH
Automotive Oscilloscope Kit

WPS500 Pressure Kit

Motorcycle Oscilloscope Kit

Milliohm and Motor Tester Kits

Other accessories

prescription

New Energy EV Test Program

School Teaching Programs

No-disassembly automotive engine stress test program

NVH Diagnostic Programs

Latest Articles

Frequently Asked Questions

The maximum input voltage for the 4223/4423 is 100 V, and for the 4225/4425(A), it is 200 V. If the signal voltage exceeds these values, an attenuator must be used to protect the oscilloscope. The 4223/4423 models are equipped with a 20:1 attenuator, the 4225/4425 models with a 10:1 attenuator, and the 4225A/4425A models use the TA499 probe (which features a built-in 10:1 attenuator).

The order from oldest to newest is as follows:

3223/3423, 4223/4423, 4225/4425, 4225A/4425A

TA499 oscilloscope probe (with built-in 10:1 attenuation); use the TA499 to measure the primary ignition voltage (for the same reason as above). For FlexRay bus testing, because FlexRay signals are very fast, you need to use a high-speed probe like this to measure them; otherwise, the signals will be distorted.

We offer comprehensive after-sales technical support. If you have any questions, please contact us; we’ll assist you by phone or online.
