TP8653 Network Sensor for PoE Power - Dual Channel with Flood Detector and Binary Inputs
P8653
P-line Web sensor with PoE power supply for measuring temperature, relative humidity with flood detector and binary inputs for binary signals.
The Web Sensors P8653 is designed to measure temperature or relative humidity from up to two external probes. This allows values from two different locations to be measured by one device.
The device is equipped with three binary inputs. the P8653 has a dedicated first binary input for connection to the flood detector LD-81 (included). The other two binary inputs can be used to connect dry contacts or binary sensors with voltage outputs. Communication with the device is realized over an Ethernet network.The P8653 can be powered by an external power adapter or by using Power over Ethernet (PoE).
Measurement data can be processed and analyzed in the following ways:
Online Processing on COMET Cloud
Processing with COMET Database Software
Integrating data into third-party systems
Warranty: 3 years
Measurement parameters
Temperature
Relative Humidity
Dual State Signal
Temperature Sensor
Measurement range: -55 to +105 °C
Measurement accuracy: according to the connected probe DSxx
Resolution: 0.1 °C
Temperature Sensor
Measurement range: according to the connected probe DSxx
Measurement accuracy: according to the connected probe DSxx
Resolution: 0.1% Relative Humidity
Binary Input
Voltage contact parameters: Voltage input level for "L": 2.5 V; Internal resistivity of the voltage source < 2 kOhm.
Input voltage range 0 to +30 V
Parameters of the voltage-free contact: 3.3 V on the unclosed contact.
Closed contact current 0.1 mA
Maximum resistivity of the contact < 5 kOhm
General Technical Data
Operating temperature: -20 to +60 °C
Channel: 1 external temperature probe or 1 connectable temperature and humidity probe
Output: Ethernet
Measurement interval: 2 s
Available temperature units: degrees Celsius, degrees Fahrenheit
Communication protocol: WWW, Modbus TCP, SNMPv1, SOAP, XML
Alert protocol: E-mail, SNMP Trap, Syslog
Battery: Ethernet powered via IEEE 802.3af or 5 Vdc
Protection level: IP30
Size: 88 x 74 x 39.5 mm
Weight: approx. 125 g
Warranty: 3 years
- P8653
- Operator's Manual
- Traceable calibration certificate
- Free software for configuring the transmitter TSensor
- COMET Cloud 3 Months License
- Flood Detector LD-81
