Measurement parameters
Temperature
Dual State Signal
Temperature Sensor - External Probe PT1000
Measurement range: -200 to +600 °C
Measurement accuracy: ±0.2 °C
Resolution: 0.1 °C
Relay Output
Quantity: 2
Maximum voltage: 50 V
Maximum current: 2 A
Maximum power: 60 VA
Binary Input
Quantity: 3
Binary input signals: dry contact, open collector or binary voltage signals.
The inputs are not isolated.
Minimum pulse duration for binary input: 500 ms
Voltage on open contacts: < 3.3 V
Low voltage level: 0 to +0.5 V
High voltage level: +3.0 to +30 V
General Technical Data
Operating temperature: -30 to +80 °C
Channel: 1 external temperature probe
Audible alarm: via built-in buzzer - switchable
Output: Ethernet
Measurement interval: 2 s
Humidity sensor temperature compensation range: covers all temperature ranges
Available Temperature Units: Celsius, Fahrenheit
Communication protocol: WWW, Modbus TCP, SNMPv1, SOAP, XML
Alarm protocols: E-mail (supports SMTP authentication), SNMP Trap, Syslog
Battery: 9-30 Vdc
Protection level: IP40
Dimensions: 136 x 117 x 45 mm
Weight: approx. 340 g
Warranty: 3 years
