VUZIX M4000 Smart Glasses

Ultra clear transparent display with unobstructed view
A solemn commitment to exceeding market standards

VUZIX M4000 Smart Glasses

Optical Waveguide Technology Realizes Versatility

  • The first enterprise-grade smart glasses to use the revolutionary Vuzix light waveguide.
  • Transparent high-definition display for full visual perception
  • High-performance Qualcomm XR1 processor
  • Ultra-long battery life with hot-swappable battery and zero downtime
  • Multiple interaction methods, supports multi-language voice control
  • Left or right monocular use, multiple wearing styles
Sample interactions

Voice, keys, touch screen.
Responds to a wide range of scenarios

3D Recognition

Quickly recognize the map.
Load 3D image model

Quality Assurance

EMC Safety Certification
All-weather kit is IP67 certified

high definition (photo, audio or television)

Resolution up to 4K 30fps

Abundant wearing styles

Suitable for multiple scenarios
Required Wearing Options

Ultra-long battery life

Power supply hot-swappable
Solve the problem of long battery life

Accessory List

- Powered by Qualcomm Qualcomm Snapdragon XR1 chipset with Android 11.0 operating system and support for secondary development
- 12.8 Million HD Camera with 4K video transmission support, so you can experience the real thing.
- Supports Bluetooth, WIFI, hotspot connection, external USB.
- Easily scan barcodes, QR codes, 3D drawings
- Compact design, free to choose the habitual eye wear
- EMC Safety Standard Certification for Medical Electrical Equipment
- IP67 & Dust & Water Resistant
- Supports multiple control modes (voice, button, touchpad), allowing you to free your hands and focus on your work.
- The industry's only uninterruptible power system, challenging the most powerful battery life.
- The same weight as a deck of playing cards for all-day comfort.
- Rugged and durable, with a drop height of up to one meter for real-life, changing work environments.
- Vuzix Appstore continues to add new apps that work with AR glasses to improve application efficiency and expand product performance

- Weighs only 3.5 ounces for all-day comfort
- Ultra-bright transparent waveguide with a 28-degree wide field of view
- Hot-swappable battery replacement allows for zero downtime when changing batteries, so you never lose contact with your partner.
- Optional extended battery for optimized use
- 3,350 mAh Anker Head-Mounted Mobile Power Supply
- 10,050 mAh Go Puck (non-headband)
- Powerful 2 to 12 hour runtime depending on battery selection and application
- Use the PDAF 12.8mp autofocus camera and 4K 30fps video streaming to optimize output without missing any details.

optics
  • Transparent Waveguide Optics
  • Display resolution: WVGA color display 854×480
  • Display Type: DLP
  • Aspect Ratio: 16:9
  • Field of view (diagonal): 28 degrees, equivalent to a 9" mobile device screen seen at 18"
  • Brightness: 5000 nits
  • Contrast ratio: > See-through 1000:1
  • 24-bit color
  • Supports left or right eye use
general
  • 8-core 2.52Ghz Qualcomm XR1
  • 6GB LPDDR4 system memory
  • 64GB Internal Flash Memory
  • Android 9.0 Operating System
  • Operating system and application OTA upgradeable
  • Multiple partners provide MDM
Certificates
  • IP67
  • Safe fall to 1 meter
Security Options
  • Vuzix M-Series Rail Eyewear frame without lenses (standard)
  • The viewer weighs less than 3.5 ounces.
  • Eyeglass frames with lenses
  • Goggles
  • Helmet Installation
  • Headband (standard)
  • Peltor Headphone Holder
Battery
  • 135 mAh internal battery supports hot-swapping of external batteries
  • 750 mAh head-mounted USB-C external battery with 3-level LEDs
  • Can be powered by a third-party USB battery pack instead of a headband battery
  • 2 - 12 hours of runtime depending on external battery selection
a control (e.g. button, text box etc) (computing)
  • 3 control buttons
  • Voice control - customizable and multi-language support
  • 2-axis touchpad with multi-finger support
Sound
  • Integrated speakers (up to 97db output)
  • Triple noise-canceling microphone
  • BT Audio: HSP/A2DP
camera
  • Still images up to 12.8 megapixels
  • Video of Gundam 4k30
  • Improved Auto Focus (PDAF)
  • Improved optical image stabilization
  • LED Flash / Scene Lighting
  • Barcode Scanning
Connectivity
  • USB 3.1 Gen 2 on USB Type-C
  • Wi-Fi 2.4/5Ghz 802.11 a/b/g/n/ac
  • Bluetooth 5.0 BR/EDR/LE
Head Tracking
  • 3 Degree of Freedom Head Tracking
  • 3-Axis Gyroscope
  • Triaxial Accelerometer
  • 3-axis magnetic/integrated compass
GPS
  • Global Positioning System/Glonass
Supported Languages
  • English
  • Spanish
  • French
  • German
  • Putonghua
  • Japanese
Environment
  • Operating Temperature 0-45ºC
  • Operating Humidity 0-95% RH
  • Storage Temperature and Humidity 10-45ºC/0-95%RH



Precision Assembly & Quality Inspection

  • Ensure product quality through rigorous workflow guidance.
  • Help complete the prompts by providing clear text, illustrations, and video instructions.
  • Free hands while working to facilitate tasks
  • Provide accurate and efficient training services to all employees

Inspection & Maintenance

  • Real-time access to remote experts for on-site viewing and problem solving
  • Save on specialist travel expenses and commuting time
  • Hands-free work, freeing up your hands and making maintenance easier.
  • Faster customer response and reduced downtime
  • Increase first-time repair rate

Warehouse Logistics

  • Reduce average picking time through AR guidance
  • Reduce order error rate through scanning, photo recording and signature confirmation.
  • Provide multi-media feedback to managers to improve workflow
  • Replace a bulky scanner and clipboard combo with a pair of smart glasses!

Telemedicine

  • Specialist doctors check the condition of emergency patients in real time, remotely check the patient's vital signs and prepare the treatment plan in advance.
  • Remote care, allowing doctors or nurses to monitor the health of multiple patients at the same time
  • High-definition video to record treatments or surgeries for training purposes
  • Faster on-demand access to medical databases for doctors in the course of life-saving treatment

Safe and Reliable Multiple Verification
