Measurement parameters
Temperature
Relative Humidity
Count (Dew Point...)
Temperature Sensor
Measurement range: -30 to +125 °C
Measurement accuracy: ±0.4 °C
Resolution: 0.1 °C
Humidity Sensor
Measurement range: 0 to 100 % relative humidity
Measurement accuracy: ±2.5 % RH (5 to 95 %, 23 °C)
Resolution: 0.1% Relative Humidity
outdoor spot
Measurement range: -60 to +80 °C
Measurement accuracy: ±1.5 °C at ambient temperature T 30 %.
Resolution: 0.1 °C
General Technical Data
Operating temperature: -30 to +80 °C
Channel: Internal temperature and humidity sensors
Measurements: Dew point, Absolute humidity, Specific humidity, Mixing ratio, Specific heat
Output: 4-20 mA, galvanic isolation
Humidity sensor temperature compensation range: covers all temperature ranges
Output Configuration: User adjustable via PC; Measurement Range + Values
Battery: 9-30 Vdc
Protection level: IP65 for electronic equipment; IP40 for sensors.
尺寸： 88.5 x 250 x 39.5 mm；閥杆長度 150 mm
Weight: approx. 150 g
Warranty: 3 years
