Measurement parameters
Temperature
Relative Humidity
Count (Dew Point...)
Dual State Signal
Temperature Sensor
Measurement range: -30 to +105°C
Measurement accuracy: ±0.4°C
Resolution: 0.1 °C
Humidity Sensor
Measurement range: 0 to 100 % relative humidity
Measurement accuracy: ±2.5 % relative humidity (5 to 95 %, 23 °C)
Resolution: 0.1% Relative Humidity
outdoor spot
Measurement range: -60 to +80 °C
Measurement accuracy: ±1.5 °C at ambient temperature T 30 %
Resolution: 0.1 °C
Relay Output
Quantity: 2
Maximum voltage: 50 V
Maximum current: 2 A
Maximum power: 60 VA
Binary Input
Quantity: 3
Binary input signals: dry contact, open collector or binary voltage signals.
The inputs are not isolated.
Minimum pulse duration for binary input: 500 ms
Voltage on open contacts: < 3.3 V
Low voltage level: 0 to +0.5 V
High voltage level: +3.0 to +30 V
General Technical Data
Operating temperature: -30 to +80 °C
Channel: 1 connectable temperature and humidity probe
Audible alarm: via built-in buzzer - switchable
Measurements: Dew point, Absolute humidity, Specific humidity, Mixing ratio, Specific heat
Output: Ethernet
Measurement interval: 2 s
Humidity Sensor Temperature Compensation Range: Covers All Temperature Ranges
Available temperature units: degrees Celsius, degrees Fahrenheit
Communication protocol: WWW, Modbus TCP, SNMPv1, SOAP, XML
Alarm protocols: E-mail (supports SMTP authentication), SNMP Trap, Syslog
Battery: 12 Vdc, 1 W maximum power consumption
Protection level: IP30 for electronic equipment; IP40 for sensors.
Dimensions: 483 x 44 x 45 mm; external probe length/diameter 88/18 mm; one rack unit
External probe cable length: 1 m
Weight: approx. 1090 g
Warranty: 3 years
