Measurement parameters
Temperature
Relative Humidity
Count (Dew Point...)
Air Pressure
Temperature Sensor
Measurement range: -30 to +105°C
Measurement accuracy: ±0.4°C
Resolution: 0.1 °C
Humidity Sensor
Measurement range: 0 to 100 % relative humidity
Measurement accuracy: ±2.5 % relative humidity (5 to 95 %, 23 °C)
Resolution: 0.1% Relative Humidity
outdoor spot
Measurement range: -60 to +80 °C
Measurement accuracy: ±1.5 °C at ambient temperature T 30 %
Resolution: 0.1 °C
Atmospheric Pressure Sensor
Measurement range: 600 to 1100 hPa
Measurement accuracy: ±1.3 hPa (23 °C, 800 to 1100 hPa)
Resolution: 0.1 hPa
General Technical Data
Operating temperature: -30 to +80 °C
Channel: Built-in atmospheric pressure sensor, 1 connectable temperature and humidity probe
Measurements: Dew point, Absolute humidity, Specific humidity, Mixing ratio, Specific heat
Output: Ethernet
Humidity Sensor Temperature Compensation Range: Covers All Temperature Ranges
Measurement interval: 2 s
Available temperature units: degrees Celsius, degrees Fahrenheit
Available pressure units: hPa, kPa, mbar, mmHg, inHg, inH2O, PSI, oz/in2
Communication protocol: WWW, Modbus TCP, SNMPv1, SOAP, XML
Alert protocol: E-mail, SNMP Trap, Syslog
Battery: 9-30 Vdc
Protection level: IP30 for electronic equipment; IP40 for sensors.
Size: 88.5 x 147.5 x 39.5 mm; stem length 75 mm
External probe cable length: 1 m
Weight: approx. 155 g
Warranty: 3 years
